FH10-1L-C
Estelle
SKU: FH10-1L-C PC

FH10-1L-C

Sale price$117.75
Colour: Polished Chrome
Item Details

Manufacturer: Estelle
Description: STEALTH Series Wall to glass hinges 90 Degree with offset plate
Material: Estelle specified forged Brass
Load Rating: 35kg per pair. Max glass width not to exceed 700mm
Glass Suitability: 10mm thickness, toughened safety glass

Features
  • Non-slip POWERGRAB ® asbestos free packers
  • Fast fit slip on design
  • Self Closing from approximately 25 degrees
  • Dual action opens inwards and outwards
  • Fixing screws, wall plugs, Allan tools and masonry drill bit supplied
  • Guaranteed for life
Fitting Instructions
  • Before attempting installation ensure the wall is strong enough to hold the required weight
  • Before attaching the hinge clean both sides of the glass with Methylated spirits at contact points
TECHNICAL DATA
